Description
Molded 7/8″-16UN (mini-style) 4-pin cable with a female connector on each end, wired pin to pin, for 7/8″ power runs. Choose the length; the configuration code updates as you pick.
Specifications
- Connectors: 7/8″-16UN screw lock, 4-pin female on both ends
- Wiring: pin to pin: 1 brown, 2 black, 3 gray, 4 green/yellow
- Lengths: 1, 2, 5 or 10 m
- Rating: 300 V, 8 A
- Materials: brass contacts, gold plated · brass coupling, nickel plated · molded black body
- Operating temperature: −40 to +105 °C (connectors)
- Compliance: RoHS, REACH
Configuration code
78-4P-FF-ST-[1M/2M/5M/10M]. Example: 78-4P-FF-ST-5M = 7/8″-16UN 4-pin female to female cable, 5 m.
Ordering
Built to order and priced by quote; standard versions ship in about 5 to 6 weeks. Pick your options and click Request a quote. Photos are representative.
Need a different length, pinout or connector combination? FormRep builds made-to-fit cable assemblies and overmolds to your drawing. Request a quote.
